Description
Length (mm) 2034 The body Aluminum alloy Frame system Iron pipe frame
Width (mm) 755 Cylinder number Single cylinder Tire structure Radial tire
Height (mm) 1096 Camshaft system Double-top camshaft(DOHC) Front rim size MT:3.0×17
Wheelbase (mm) 1390 Bore X Stoke (mm) 80 x 62 Rear rim size MT:4.5×17
Loading capacity (kg) 167 Cooling system Water cooling Front tire size;Pressure 110/70R17;54S 250KPa
Curb weight (kg) 175 Fuel tank Petrol Rear tire size;Pressure 160/60R17;69S 250KPa
Ground clearance (mm) 168 Compression ratio 12.5:1 Front brake size ABS Disk brake
Fuel tank volume (L) 15 Displacement(ml) 312 Rear brake size ABS Disk brake
Seat height (mm) 795 Fuel supply system Fuel injection Headlight/taillight/turning signal light LED
Fuel injection system BOSCH ABS brake system BOSCH
Ignition system Electric ignition Battery 12.8V-10Ah
Transmission system Oil sealing chain Homologation Euro 5
Idling speed (r/min) 1600 ± 100
Maximum power (kW/rpm) 26 / 9500
Maximum torque (N.m/rpm) 30 / 7500
Transmission Constant mesh 6-section transmission
Gear International gear
Clutch Wet type multi-pieces
Economical consumption of fuel (L/km) 3.2 /100
