Description
Length (mm) 2037 The body Aluminum alloy Frame system Iron pipe frame
Width (mm) 830 Cylinder number Single cylinder Tire structure Radial tire
Height (mm) 1360(High version) 1342(Low version) Camshaft system Double-top camshaft(DOHC) Front rim size MT:3.0×17
Wheelbase (mm) 1400 Bore X Stoke (mm) 80 x 62 Rear rim size MT:4.5×17
Net weight (kg) 155 Cooling system Water cooling Front tire size 110/70R17
Full load (kg) 165 Fuel tank Gasoline Rear tire size 160/60R17
Ground clearness (mm) 186(High version) 167(Low version) Compression ratio 12.5:1 Front brake size Disk brake
Fuel tank volume (L) 19 Displacement(ml) 312 Rear brake size Disk brake
Seat height (mm) 830(High version) 795(Low version) Fuel supply system fuel injection Headlight/taillight/turning signal light LED
Fuel injection system Delphi ABS brake system Bosch
Ignition system Electric ignition
Transmission system Oil sealing chain
Idling speed (r/min) 1600 ± 100
Maximum power (kW/rpm) 26 / 9500
Maximum torque (N.m/rpm) 30 / 7500
Transmission Constant mesh 6-section transmission
Gear International gear
Clutch Wet type multi-pieces
Economical consumption of fuel (L/km) 3.2 /100
