Description
Length (mm) 2080 The body Aluminum alloy Frame system Iron pipe frame
Width (mm) 850 Cylinder number Single cylinder Tire structure Radial tire
Height (mm) 1320 Camshaft system Double-top camshaft(DOHC) Front rim size MT:3.0×17; MT:2.5×19
Wheelbase (mm) 1394 Bore X Stoke (mm) 80 x 62 Rear rim size MT:4.5×17
Loading capacity(kg) 165 Cooling system Water cooling Front tire size;Pressure 110/70R17;54S 250Kpa
110/80R19;59S or 59V 250Kpa
Curb weight(kg) 193 Fuel 95 and above Rear tire size;Pressure 160/60R17;69S or 69H 250Kpa
Ground clearance (mm) 168 Compression ratio 12.5:1 Front brake size Disk brake
Fuel tank volume (L) 19 Displacement(ml) 312 Rear brake size Disk brake
Seat height (mm) 830/795 Fuel supply system Fuel injection Headlight/taillight/turning signal light LED
Fuel injection system BOSCH Brake system Dual channel ABS
Ignition system Electric ignition Battery 12.8V-10Ah
Transmission system Oil sealing chain Homologation Euro 5
Idling speed (r/min) 1600 ± 100
Maximum power (kW/rpm) 26 / 9500
Maximum torque (N.m/rpm) 30 / 7500
Transmission Constant mesh 6-section transmission
Gear International gear
Clutch Wet type multi-pieces
Economical consumption of fuel (L/km) 3.2 /100
